Goodrive100-PV Series Solar Pumping VFD Product overview
4
2 Product overview
2.1 Unpacking inspection
Check as follows after receiving products:
1. Check that there are no damage and humidification to the package. If not, please
contact with local agents or offices.
2. Check the information on the type designation label on the outside of the package to
verify that the drive is of the correct type. If not, please contact with local dealers or offices.
3. Check that there are no signs of water in the package and no signs of damage or breach
to the VFD. If not, please contact with local dealers or offices.
4. Check the information on the type designation label on the outside of the package to
verify that the name plate is of the correct type. If not, please contact with local dealers or
offices.
5. Check to ensure the accessories (including user’s manual and control keypad) inside
the device is complete. If not, please contact with local dealers or offices.
2.2 Name plate
Figure 2-1 Name plate
Note: This is the example of Goodrive100-PV standard products and the CE\TUV\IP20
certifications are marked according to the reality.
2.3 Type designation key
The type designation contains information on the VFD. The user can find the type designation
on the type designation label attached to the VFD or the simple name plate.
GD100 – 5R5G – 4 5 – PV
① ② ④③ ⑤
I P2 0
S/N:
Model: GD100-2R2G-S2-PV
Power(Output): 2.2kW
Input: DC 150V-440V
AC 1PH 220V (-15%)-240V (+10%) 24A 47 Hz-63Hz
Output: AC 3PH 0V-Uinput 10A 0Hz-400Hz
