Goodrive100-PV Series Solar Pumping VFD Keypad operation procedure

4 Keypad operation procedure

4.1 Keypad introduction

Keypads are used to control GD100-PV series VFDs, read the state data and adjust

parameters. If it is necessary to connect the keypad to other external device, you can use the

standard RJ45 cable with crystal head as the external extension cable.

Figure 4-1 Keypad diagram for VFDs ≤ 2.2kW

PRG

ESC

DATA

QUICK

JOG

SHIFT

RUN

STOP

RST

RUN/TUNE FWD/REV LOCAL/REMOT TRIP

RPM

Figure 4-2 Keypad diagram for VFDs ≥ 4kW

Note: External keypads can be configured for VFDs ≤ 2.2kW. The keypads of VFDs ≥ 4kW

can be used as external keypads.
