Goodrive100-PV Series Solar Pumping VFD Options and use
68
Model
Recommended cable size
(mm
2
)
Terminal
screw
Tightening
torque
(Nm)
(+)/(-), R/S/T, U/V/W
PE
GD100-2R2G-2-PV
2.5
2.5
M4
1.2–1.5
GD100-7R5G-4-PV
4
4
M5
2–2.5
GD100-004G-2-PV
4
4
M5
2–2.5
GD100-011G-4-PV
6
6
M5
2–2.5
GD100-5R5G-2-PV
6
6
M5
2–2.5
GD100-015G-4-PV
10
10
M5
2–2.5
GD100-7R5G-2-PV
10
10
M5
2–2.5
GD100-018G-4-PV
16
16
M5
2–2.5
GD100-022G-4-PV
25
16
M5
2–2.5
GD100-030G-4-PV
25
16
M6
4–6
GD100-037G-4-PV
35
16
M6
4–6
GD100-045G-4-PV
35
16
M8
10
GD100-055G-4-PV
50
25
M8
10
GD100-075G-4-PV
70
35
M8
10
GD100-090G-4-PV
95
50
M12
31–40
GD100-110G-4-PV
120
70
M12
31–40
GD100-132G-4-PV
185
95
M12
31–40
GD100-160G-4-PV
240
95
M12
31–40
GD100-185G-4-PV
120*2P
150
M12
31–40
GD100-200G-4-PV
120*2P
150
M12
31–40
Note:
 For the cable selection for model IP54, see the cables applicable to the models with the
same power as model IP54 in this table.
 It is appropriate to use the recommended cable size under 40°C and rated current. The
wiring distance should be no more than 100m.
 If the control cable and power cable must cross, the angle between them must be 90°.
 If the inside of the VFD is moist, the insulation resistance will decrease. If there is moisture
in the VFD, dry up the VFD and measure the humidity again.
