Goodrive300 Series VFD Basic operation instruction

126

Start

Power on after right wiring

Restore to the factory

parameters（P00.18=1）

Motor type selection

（P02.00）

Set P02.01~P02.05 Set P02.15~P02.19

Press QUICK/JOG to jog

If the rotation direction is wrong, power

off to change the wires and repower on

Set autotuning

Set P00.15=1 to achieve

rotation autotuning

Set P00.15=3 to achieve

static autotuning 2

Press RUN to autotune

and then stop

Set running frequency

Set speed control mode

(P00.00)

P00.00=0 P00.00=1 P00.00=2

Set P03 group parameters Set P03 group parameters Set P04 group parameters

Set P01 group parameters

Run after a run command

is received

Stop after a stop

command is received

End

Set running command

channel (P00.01,P00.02)

Set P00.15=2 to achieve

static autotuning 1

Note: If fault occurs, please do as the Chapter 8 "Fault tracking". Esitimate the fault reason and settle

the issue.
