INVT GD300-037G-4 User Manual

Goodrive300 Series VFD Basic operation instruction
169
Function
code
Name
Detailed instruction of parameters
Default
value
P05.26
Switch-on delay of S7
terminal
0.000–50.000s
0.000s
P05.27
Switch-off delay of S7
terminal
0.000–50.000s
0.000s
P05.28
Switch-on delay of S8
terminal
0.000–50.000s
0.000s
P05.29
Switch-off delay of S8
terminal
0.000–50.000s
0.000s
P05.30
Switch-on delay of HDI
terminal
0.000–50.000s
0.000s
P05.31
Switch-off delay of HDI
terminal
0.000–50.000s
0.000s
P07.39
Bus voltage at current
fault
0
P17.12
Digital input terminals
state
0
7.12 Digital output
Goodrive300 series VFDs have 2 relay output terminals, 1 open collector output terminal Y, and 1
high-speed pulse output terminal (HDO) in the standard configuration. All functions of the digital
output terminals are programmable by using function codes, where the HDO can be set to high-speed
pulse output or switch output through function codes.
