INVT GD300-037G-4 User Manual

Goodrive300 Series VFD Basic operation instruction
145
Function
code
Name
Detailed instruction of parameters
Default
value
P02.08
Leakage inductance of
asynchronous motor 1
0.1–6553.5mH
Depend
on model
P02.09
Mutual inductance of
asynchronous motor 1
0.1–6553.5mH
Depend
on model
P02.10
Non-load current of
asynchronous motor 1
0.1–6553.5A
Depend
on model
P02.15
Rated power of
synchronous motor 1
0.1–3000.0kW
Depend
on model
P02.16
Rated frequency of
synchronous motor 1
0.01Hz–P00.03 (Max. frequency)
50.00Hz
P02.17
Number of poles pairs for
synchronous motor 1
1–50
2
P02.18
Rated voltage of
synchronous motor 1
0–1200V
Depend
on model
P02.19
Rated current of
synchronous motor 1
0.8–6000.0A
Depend
on model
P02.20
Stator resistor of
synchronous motor 1
0.001–65.535Ω
Depend
on model
P02.21
Direct axis inductance of
synchronous motor 1
0.01–655.35mH
Depend
on model
P02.22
Quadrature axis
inductance of
synchronous motor 1
0.01–655.35mH
Depend
on model
P02.23
Back EMF constant of
synchronous motor 1
0–10000
300
P05.01–P05
.09
Multi-function digital input
terminals
(S1–S8, HDI) function
selection
35: Shift from motor 1 to motor 2
P08.31
Motor shifting
LED ones: shifting channel
0: terminal shifting
1: Modbus communication shifting
2: PROFIBUS/CANopen communication
shifting
3: Ethernet communication shifting
4: Reserved
LED tens: shifting enabling in operation
00
