Goodrive300 Series VFD Peripherial options and parts
272
Model
Input reactor
DC reactor
Output reactor
GD300-011G-4
ACL2-011-4
/
OCL2-011-4
GD300-015G-4
ACL2-015-4
/
OCL2-015-4
GD300-018G-4
ACL2-018-4
/
OCL2-018-4
GD300-022G-4
ACL2-022-4
/
OCL2-022-4
GD300-030G-4
ACL2-030-4
/
OCL2-030-4
GD300-037G-4
ACL2-037-4
DCL2-037-4
OCL2-037-4
GD300-045G-4
ACL2-045-4
DCL2-045-4
OCL2-045-4
GD300-055G-4
ACL2-055-4
DCL2-055-4
OCL2-055-4
GD300-075G-4
ACL2-075-4
DCL2-075-4
OCL2-075-4
GD300-090G-4
ACL2-110-4
DCL2-090-4
OCL2-110-4
GD300-110G-4
ACL2-110-4
DCL2-132-4
OCL2-110-4
GD300-132G-4
ACL2-132-4
DCL2-132-4
OCL2-132-4
GD300-160G-4
ACL2-160-4
DCL2-160-4
OCL2-160-4
GD300-200G-4
ACL2-200-4
DCL2-220-4
OCL2-200-4
GD300-220G-4
ACL2-250-4
DCL2-220-4
OCL2-250-4
GD300-250G-4
ACL2-250-4
DCL2-280-4
OCL2-250-4
GD300-280G-4
ACL2-280-4
DCL2-280-4
OCL2-280-4
GD300-315G-4
ACL2-315-4
DCL2-315-4
OCL2-315-4
GD300-350G-4
Standard
DCL2-400-4
OCL2-350-4
GD300-400G-4
Standard
DCL2-400-4
OCL2-400-4
GD300-500G-4
Standard
DCL2-500-4
OCL2-500-4
Note:
1. The rated derate voltage of the input reactor is 2%±15%.
2. The power factor of the input side is above 90% after installing DC reactor.
3. The rated derate voltage of the output reactor is 1%±15%.
4. Above options are external, the customer should indicate when purchasing.
D.6.2 AC 3PH 380V(-10%)V–550V(+10%)
Model
Input reactor
DC reactor
Output reactor
GD300-004G-5
/
/
/
GD300-5R5G-5
/
/
/
GD300-7R5G-5
/
/
/
GD300-011G-5
/
/
/
GD300-015G-5
ACL2-030-6
/
OCL2-030-6
GD300-018G-5
ACL2-030-6
/
OCL2-030-6
GD300-022G-5
ACL2-055-6
DCL2-055-6
OCL2-055-6
GD300-030G-5
ACL2-055-6
DCL2-055-6
OCL2-055-6
