Goodrive300 Series VFD Basic operation instruction
143
Ready
P00.01=0
P02.00
P02.00=1 P02.00=0
（P02.12–P02.19） （P02.01–P02.05）
P00.15=1 P00.15=3
P00.15
Press "RUN" to begin autotuning
Display "-END-"
Autotuning
SM AM
P00.15=2
Autotuning end
Note:
1. Set the motor parameters according to the name plate of the motor.
2. During the motor autotune, de-couple the motor form the load if rotation autotune is selected to
