INVT GD300-075G-4 - Page 165

Goodrive300 Series VFD Basic operation instruction
160
Set value
Function
Instructions
communication
15
Set value 2 of Modbus
communication
-1000–1000,1000 corresponds to 100.0%
16
Setting value 1 of
PROFIBUS/CANOPEN
communication
-1000–1000,1000 corresponds to 100.0%
17
Setting value 2 of
PROFIBUS/CANOPEN
communication
-1000–1000,100 corresponds to 100.0%
18
Setting value 1 of Ethernet
communication
-1000–1000,1000 corresponds to 100.0%
19
Setting value 2 of Ethernet
communication
-1000–1000,100 corresponds to 100.0%
20–21
Reserved
22
Torque current
(corresponding to triple the
rated current of the motor)
0–3 times of the rated current of the motor
23
Ramp reference frequency
(with sign)
0–max. output frequency
24–30
Reserved
Related parameters
Function
code
Name
Detailed instruction of parameters
Default
value
P06.00
HDO output
0: Open collector high speed pulse
output
1: Open collector output
0
P06.14
AO1 output
0: Running frequency
1: Set frequency
2: Ramp reference frequency
3: Running rotation speed (relative to 2
times the synchronous rotation speed of
the motor)
4: Output current (relative to 2 times the
rated current of the VFD)
5: Output current (relative to 2 times the
rated current of the motor)
6: Output voltage (relative to 1.5 times
the rated voltage of the VFD)
0
P06.15
AO2 output
0
P06.16
HDO high-speed pulse
output
0
