INVT GD300-075G-4 - Page 171

Goodrive300 Series VFD Basic operation instruction
166
Set
value
Function
Instructions
communication
command channel will be shifted into communication
running command channel and the running command
channel will come back to the original state if the
function terminal is invalid.
39
Pre-excitation commands
Perform pre-exciting if the terminal is valid until the
terminal is invalid.
40
Power consumption clear
The power consumption will be cleared after the
command is valid.
41
Power consumption retention
If the command is valid, the current running of the
VFD will not affect its power consumption.
42–60
Reversed
61
PID pole switching
Switch the output pole of PID and be used with
P09.03
62–63
Reversed
Related parameters
Function
code
Name
Detailed instruction of parameters
Default
value
P05.00
HDI input selection
0: High pulse input
1: Digital input
0
P05.01
S1 terminals function
selection
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting
(DOWN)
12: Frequency setting clear
13: Shift between A setting and B setting
14: Shift between combination setting
and A setting
15: Shift between combination setting
1
P05.02
S2 terminals function
selection
4
P05.03
S3 terminals function
selection
7
P05.04
S4 terminals function
selection
0
P05.05
S5 terminals function
selection
0
P05.06
S6 terminals function
selection
0
P05.07
S7 terminals function
selection
0
P05.08
S8 terminals function
selection
0
P05.09
HDI terminal function
selection
0
