Goodrive300 Series VFD Product overview
13
1. The input current of VFDs 1.5–315kW is detected when the input voltage is 380V and there are no
DC reactors and input/output reactors.
2. The input current of VFDs 350–500kW is detected when the input voltage is 380V and there are
input reactors.
3. The rated output current is defined as the output current generated when the output voltage is
380V.
4. Within the allowed input voltage range, the output current cannot exceed the rated output current,
and the output power cannot exceed the rated output power.
3.6.2 AC 3PH 380V (-10%)–550V (+10%)
Model
Rated output power
(kW)
Rated input current
(A)
Rated output
current (A)
GD300-004G-5
4
11
8
GD300-5R5G-5
5.5
15
10
GD300-7R5G-5
7.5
19
14
GD300-011G-5
11
26
20
GD300-015G-5
15
32
26
GD300-018G-5
18.5
40
34
GD300-022G-5
22
48
42
GD300-030G-5
30
60
53
GD300-037G-5
37
66
63
GD300-045G-5
45
78
75
GD300-055G-5
55
95
92
GD300-075G-5
75
126
120
Note:
1. The input current of VFDs 1.5–75kW is detected when the input voltage is 500V and there are no
DC reactors and input/output reactors.
2. The rated output current is defined as the output current generated when the output voltage is
500V.
3. Within the allowed input voltage range, the output current cannot exceed the rated output current,
and the output power cannot exceed the rated output power.
3.6.3 AC 3PH 520V (-15%)–690V (+10%)
Model
Rated output power
(kW)
Rated input current
(A)
Rated output
current (A)
GD300-022G-6
22
35
27
GD300-030G-6
30
40
35
GD300-037G-6
37
47
45
GD300-045G-6
45
52
52
