Goodrive300 Series VFD Peripherial options and parts
278
Model
Model of
braking
unit
Brake
resistor
value
matched
with 100%
brake
torque (Ω)
Dissipation
power of
brake
resistor (kW)
(10% brake)
Dissipated
power of
brake
resistor
(kW)
(50%
brake)
Dissipated
power of
brake
resistor
(kW)
(80%
brake)
Min
allowed
brake
resistor
(Ω)
GD300-1R5G-4
Embedded
braking units
326
0.23
1.1
1.8
170
GD300-2R2G-4
222
0.33
1.7
2.6
130
GD300-004G-4
122
0.6
3
4.8
80
GD300-5R5G-4
89
0.75
4.1
6.6
60
GD300-7R5G-4
65
1.1
5.6
9
47
GD300-011G-4
44
1.7
8.3
13.2
31
GD300-015G-4
32
2
11
18
23
GD300-018G-4
27
3
14
22
19
GD300-022G-4
22
3
17
26
17
GD300-030G-4
17
5
23
36
17
GD300-037G-4
DBU100H-060-4
13
6
28
44
11.7
GD300-045G-4
DBU100H-110-4
10
7
34
54
6.4
GD300-055G-4
8
8
41
66
GD300-075G-4
6.5
11
56
90
GD300-090G-4
DBU100H-160-4
5.4
14
68
108
4.4
GD300-110G-4
4.5
17
83
132
GD300-132G-4
DBU100H-220-4
3.7
20
99
158
3.2
GD300-160G-4
DBU100H-320-4
3.1
24
120
192
2.2
GD300-200G-4
2.5
30
150
240
GD300-220G-4
DBU100H-400-4
2.2
33
165
264
1.8
GD300-250G-4
2.0
38
188
300
GD300-280G-4
Two
DBU100H-320-4
3.6×2
21×2
105×2
168×2
2.2×2
GD300-315G-4
3.2×2
24×2
118×2
189×2
GD300-350G-4
2.8×2
27×2
132×2
210×2
GD300-400G-4
2.4×2
30×2
150×2
240×2
GD300-500G-4
Two
DBU100H-400-4
2×2
38×2
186×2
300×2
1.8×2
Note:
1. Select the resistor and power of the brake unit according to the data our company provided.
2. The brake resistor may increase the brake torque of the VFD. The preceding table describes the
resistance and power for 100% brake torque, 10% brake usage, 50% brake usage, and 80% brake
