Goodrive300 Series VFD Function parameters
42
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
STOP/RST simultaneously in running state to
make the VFD coast to stop.
1: Terminal ("LOCAL/REMOT" flickering)
Carry out the running command control by the
forward rotation, reverse rotation and forward
jogging and reverse jogging of the multi-function
terminals
2: Communication ("LOCAL/REMOT" on)
The running command is controlled by the upper
monitor via communication
P00.02
Communicatio
n running
commands
Select the controlling communication command
channel of the VFD.
0: Modbus communication channel
1: PROFIBUS\CANopen communication channel
2: Ethernet communication channel
3: Reserved
Note: 1, 2 and 3 are extension functions which
need corresponding extension cards.
0
○
P00.03
Max. output
frequency
This parameter is used to set the maximum
output frequency of the VFD. Users should pay
attention to this parameter because it is the
foundation of the frequency setting and the speed
of acceleration and deceleration.
Setting range: P00.04–400.00Hz
50.00
Hz
◎
P00.04
Upper limit of
the running
frequency
The upper limit of the running frequency is the
upper limit of the output frequency of the VFD
which is lower than or equal to the maximum
frequency.
Setting range: P00.05–P00.03 (Max. output
frequency)
50.00
Hz
◎
P00.05
Lower limit of
the running
frequency
The lower limit of the running frequency is that of
the output frequency of the VFD.
The VFD runs at the lower limit frequency if the
set frequency is lower than the lower limit one.
Note: Max. output frequency ≥ Upper limit
frequency ≥ Lower limit frequency
Setting range: 0.00Hz–P00.04 (Upper limit of the
running frequency)
0.00Hz
◎
