INVT Goodrive170-PV Series User Manual

Goodrive170-PV Series Solar Pump Inverter Function parameter list
-26-
Function
code
Name
Description
Default
Modify
P02.19
Rated current of
SM
0.8–6000.0A
function. Whether
parameter autotuning
can be performed
properly depends on the
settings of the motor
nameplate parameters.
In addition, you need to
configure a motor
according to the
standard motor
configuration of the
inverter. If the power of
the motor is greatly
different from that of the
standard motor
configuration, the control
performance of the
inverter degrades
significantly.
Note: Resetting the
rated power of the motor
(P02.15) can initialize the
parameters P02.02–
P02.10.
Model
depended
◎
P02.20
Stator
resistance of
SM
0.001–
65.535Ω
After motor parameter
autotuning is properly
performed, the values of
P02.20–P02.23 are
automatically updated.
These parameters are
the benchmark
parameters for
high-performance vector
control, directly affecting
the control performance.
Note: Do not modify
these parameters unless
it is necessary.
Model
depended
○
P02.21
Direct-axis
inductance of
SM
0.01–
655.35Mh
Model
depended
○
P02.22
Quadrature-axis
inductance of
SM
0.01–
655.35Mh
Model
depended
○
P02.23
Counter-emf of
SM
0–10000
300
○
