INVT Goodrive170-PV Series

Goodrive170-PV Series Solar Pump Inverter Power frequency & PV switching solution
-66-
Symbol
Terminal name
Description
(+)、(-)
PV DC input
Input terminals of photovoltaic panels.
U, V, W
Inverter output
3PH AC output terminals, connected to the pump
motor.
Safety
protection
grounding
Grounding terminal for safe protection; each machine
must be properly grounded.
Note: The grounding terminal is located at the bottom
of the chassis.
C.3 Parameter setting method
Connect the external PV voltage detection signal to HDI terminal (auto switching by
default), and the PV voltage detection threshold is 300V.
After the correct connection, set P15.32 to 0.
