2 Product overview
2.1 Unpacking inspection
Check the following after receiving the product.
1. Whether the packing box is damaged or dampened.
2. Whether the model identifier on the exterior surface of the packing box is consistent
with the purchased model.
3. Whether the interior surface of the packing box is abnormal, for example, in wet
condition, or whether the enclosure of the inverter is damaged or cracked.
4. Whether the inverter nameplate is consistent with the model identifier on the exterior
surface of the packing box.
5. Whether the accessories (including the manual and keypad) inside the packing box
are complete.
2.2 Product nameplate
IP20
Model:GD170-004-4-PV
Power(Output):4kW Protective class:1
Input:DC Vmax PV 800V Isc PV
AC 3PH 380V(-15%)-440V(+10%) 13.5A 47Hz-63Hz
Output:AC 3PH 0V-400V 9.5A 0Hz-400Hz
S/N: Made in China
Shenzhen INVT Electric Co.,Ltd.
Note: This is a nameplate example of a standard inverter product. The CE/IP20 marking
on the top right will be marked according to actual certification conditions.
2.3 Model designation code
A model designation code contains product information. You can find the model
designation code on the inverter nameplate and simplified nameplate.
GD170 – 004 – 4 – PV
① ② ④③
Field
No.
Description
Content
Abbreviation
of product
series
①
Abbreviation of
product series
GD is short for Goodrive.
