INVT Goodrive170-PV Series User Manual

Goodrive170-PV Series Solar Pump Inverter Recommended solar module configuration
-62-
Appendix B Recommended solar module configuration
B.1 Recommended solar module configuration for solar pump inverters
Solar pump
inverter model
Open-circuit voltage class of solar module
37±1V
45±1V
Module power
± 5Wp
Modules per
string * Strings
Module power
± 5Wp
Modules per
string *
Strings
GD170-2R2-4-PV
250
18*1
300
15*1
GD170-004-4-PV
250
20*1
300
16*1
GD170-5R5-4-PV
250
18*2
300
15*2
GD170-7R5-4-PV
250
18*2
300
15*2
GD170-011-4-PV
250
18*3
300
15*3
GD170-015-4-PV
250
18*4
300
15*4
GD170-018-4-PV
250
18*5
300
15*5
GD170-022-4-PV
250
18*6
300
15*6
GD170-030-4-PV
250
18*8
300
15*8
GD170-037-4-PV
250
18*9
300
15*9
GD170-045-4-PV
250
18*11
300
15*11
B.2 Recommended solar module configuration for inverters with boost
module
PP100-3R2-PV
+
Solar pump inverter
Max. DC
input
current
Open-circuit voltage class of solar module
37±1V
45±1V
(A)
Module
power ±
5Wp
Modules
per string *
Strings
Module
power ±
5Wp
Modules
per string *
Strings
GD170-2R2-4-PV
12
250
13*1
300
11*1
