Goodrive170-PV Series Solar Pump Inverter Function parameter list
-29-
Function
code
Name
Description
Default
Modify
P04.11
High-frequency
oscillation
control factor
certain frequencies, which may cause
unstable motor running, or even inverter
overcurrent. You can adjust the two
function codes properly to eliminate such
phenomenon.
Setting range of P04.10 and P04.11: 0–100
Setting range of P04.12: 0.00Hz–P00.03
(Max. output frequency)
10
○
P04.12
Vibration
control
threshold
30.00Hz
○
P04.34
Two phase
control
selection of
single-phase
motor
Ones place: Reserved
Tens place: Reversal of the secondary
winding (V-phase) voltage
0: Not reversed; 1: Reversed
Setting range: 0–0x11
0x00
◎
P04.35
Voltage ratio of
V-phase and
U-phase
0.00–2.00
1.40
○
P05 group Input terminals
Function
code
Name
Description
Default
Modify
P05.00
HDI input
type
0: HDI is high-speed pulse input. See
P05.49–P05.54.
1: HDI is digital input
1
◎
P05.01
Function of
S1
0: No function
1: Run forward
2: Run reversely
3: Three-wire running control
4–5: Reserved
6: Coast to stop
7: Reset faults
8: Pause running
9: External fault input
10–35: Reserved
36: Switch the running command channel to
keypad
37: Switch the running command channel to
terminal
42
◎
P05.02
Function of
S2
43
◎
P05.03
Function of
S3
44
◎
P05.04
Function of
S4
45
◎
P05.05
Function of
S5
1
P05.09
Function of
HDI
46
◎
