INVT Goodrive300-01A Series - Page 52

Goodrive300-01A series VFD for air compressor Function code description
-48-
Function
code
Name
Parameter description
Default
value
Modify
Setting range: 0.00–10.00V
P17.22
PT2 input voltage
Display analog input voltage value of PT2
channel. Under air-compressor mode,
connect to PT100 thermal resistor
temperature sensor, different temperature
generates corresponding resistor value, and
different resistor value corresponds to
corresponding input voltage, therefore, input
voltage value can correspond to
corresponding detection temperature. Input
voltage P18.32- P18.33 correspond to
-20°C to +150°C .
Setting range: 0.00–10.00V
0.00V
●
P17.23
PID reference value
Display the set value of discharge pressure
signal. 100% corresponds to the upper limit
value of discharge pressure sensor (P18.04)
(if P18.37=1, 100% corresponds to P18.38).
Setting range: -100.0–100.0%
0.0%
●
P17.24
PID feedback value
Display the detection value of discharge
pressure signal.
Setting range: -100.0–100.0%
0.0%
●
P17.25
Motor power factor
-1.00–1.00
0.0
●
P17.26
Current running time
0–65535m
0m
●
P17.28
ASR controller output
-300.0%–300.0% (rated motor current)
0.0%
●
P17.29
Magnetic pole angle of
synchronous motor
0.0–360.0
0.0
●
P17.30
Phase compensation
quantity of
synchronous motor
-180.0–180.0
0.0
●
P17.36
Output torque
-3000.0Nm–3000.0Nm
0.0Nm
●
P17.38
PID output value
Display the output value of PID control of
discharge pressure signal; 100% corresponds
to max. output frequency P00.03.
Setting range: -100.00–100.00%
0.00%
●
P18.00
Air compressor control
mode
0: Invalid;
1: Air-compressor control mode
Note: When P18.00=1, P19 air-compressor
state checking group is valid.
0
◎
P18.01
Sleep function
0: Invalid
1
◎
