Goodrive300-01A series VFD for air compressor Function code description
-53-
Function
code
Name
Parameter description
Default
value
Modify
P18.32.
Connect to the resistor whose resistance is
the same with that of PT100 at 150°C , read
the voltage value of P17.22, and input it to
P18.33.
Setting range: 0.00–10.00V
Note: When restoring to default values, this
value will stay in current value.
P18.34
Auxiliary temperature
protection enable
0: Invalid
1: Valid
0
◎
P18.35
Auxiliary temperature
pre-alarm
-20–150
When P18.34 is enabled and auxiliary
temperature is higher than P18.35, the
system indicates auxiliary temperature
pre-alarm by setting BIT8 of P19.14 to 1.
105°C
○
P18.36
Auxiliary temperature
alarm
-20–150
When P18.34 is enabled and auxiliary
temperature is higher than P18.36, the
system indicates auxiliary temperature alarm
by setting BIT10 of P19.14 to 1, and
emergency-stop will be applied.
110°C
○
P18.37
Pressure sensor
channel
0: Discharge pressure P1,
auxiliary pressure P2
1: Discharge pressure P2,
auxiliary pressure P1
0
◎
P18.38
Upper limit of pressure
sensor P2
0.00–20.00 Mpa
It is related to the actual range of pressure
sensor, the corresponding voltage of P18.04
is P05.44.
Note: When restoring to default values, the
value will stay in current value.
1.60Mpa
◎
P18.39
Auxiliary pressure
protection enable
0: Invalid
1: Valid
0
◎
P18.40
Auxiliary pressure
pre-alarm
0.00–20.00
When P18.39 is enabled and the auxiliary
pressure is larger than P18.40, the system
indicates auxiliary pressure pre-alarm by
setting BIT7 of P19.14 to 1.
0.90Mpa
○
P18.41
Auxiliary pressure
alarm
0.00–20.00
When P18.39 is enabled and the auxiliary
1.00Mpa
○
