INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Function parameters
123
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P17.21
AI3 input
voltage
Display analog AI2 input signal.
Range: -10.00–10.00V
0.00V
●
P17.22
HDI input
frequency
Display HDI input frequency.
Range: 0.000–50.000kHz
0.000
kHz
●
P17.23
PID reference
Display PID given value.
Range: -100.0–100.0%
0.0%
●
P17.24
PID feedback
Display PID response value.
Range: -100.0–100.0%
0.0%
●
P17.25
Power factor
of the motor
Display the current power factor of the motor.
Range: -1.00–1.00
0.0
●
P17.26
Current
running time
Display the current running time of the VFD.
Range:0–65535m
0m
●
P17.27
Simple PLC
and the
current step of
the multi-step
speed
Display simple PLC and the current stage of the
multi-step speed.
Range: 0–15
0
●
P17.28
ASR controller
output
The percentage of the rated torque of the
corresponding motor, display ASR controller
output.
Range: -300.0%–300.0% (the rated current of the
motor)
0.0%
●
P17.29
Magnetic pole
angle of SM
Display synchronous motor Magnetic pole angle.
Range: 0.0–360.0
0.0
●
P17.30
Phase
compensation
of SM
Display synchronous motor phase compensation.
Range: -180.0–180.0
0.0
●
P17.31
High-frequenc
y
superimposed
current of SM
Display synchronous motor high-frequency
Superimposed current.
Range: 0.0%–200.0% (the rated current of the
motor)
0.0
●
P17.32
Magnetic flux
linkage
Display the magnetic flux linkage of the motor.
Range: 0.0%–200.0%
0.0%
●
P17.33
Exciting
current
reference
Display the exciting current reference in the
vector control mode.
Range: -3000.0–3000.0A
0.0A
●
P17.34
Torque current
Display the torque current reference in the vector
0.0A
●
