INVT Goodrive300 Series User Manual

Goodrive300 Series VFD Basic operation instruction
163
This parameter is used to set the function corresponds to the digital multi-function terminals.
Note: two different multi-function terminals cannot be set as one function.
Set
value
Function
Instructions
0
No function
The VFD does not work even there is input signal. It is
necessary to set the terminal which cannot be used to
non-function to avoid misacting.
1
Forward running(FWD)
The forward or reverse rotation of the VFD can be
controlled by the external terminals.
2
Reverse running(REV)
3
3-wire running control
The terminal can determine the running mode of the
VFD is 3-wire control mode. Refer to P05.13 for
detailed instruction of 3-wire control mode.
4
Forward jogging
See P08.06, P08.07 and P08.08 for jogging
frequency, jogging ACC/DEC time.
5
Reverse jogging
6
Coast to stop
The VFD closes off the output. The motor is not
controlled by the VFD during the stopping. This
method is usually to be used when the load inertia is
big and it has no requirement to the stopping time.
It has the same meaning with the "coast to stop" in
P01.08 and usually used in remote control.
7
Fault reset
External fault reset. It has the same function with the
reset function of STOP/RST on the keypad. This
function can realize remote fault reset.
8
Operation pause
The VFD decelerates to stop. But all running
parameters are in the memory state. For example,
PLC parameters, traverse parameters and PID
parameters. After the signal disappears, the VFD will
come back to the state before stopping.
9
External fault input
When the external fault signal is sent to the VFD, the
VFD will report the fault and stop.
10
Frequency setting up(UP)
This parameter is used to modify the increasing and
decreasing command during the external terminal
given frequency.
K1
K2
K3
UP terminal
DOWN terminal
UP/DOWM
terminals
COM
12
Frequency setting
down(DOWN)
12
Frequency
increasing/decreasing setting
clear
