Goodrive300 Series VFD Basic operation instruction
164
Frequency increasing/decreasing setting clear
terminal can cancel the assistant channel frequency
set by the internal UP/DOWN of the VFD to make the
given frequency restore to the frequency given by the
main given frequency channel.
Switch between A setting and
B setting
This function can realize the shifting between the
frequency setting channels.
The 13
th
function can realize the shifting between A
frequency given channel and B frequency given
channel.
The 14
th
function can realize the shifting between A
frequency given channel and the combination setting
channel set by P00.09
The 15
th
function can realize the shifting between B
frequency given channel and the combination setting
channel set by P00.09
Switch between A setting and
combination setting
Switch between B setting and
combination setting
Multi-step speed terminal 1
The 16 stage speeds can be set by the combination of
digital state of four terminals.
Note: multi-step speed 1 is the low bit, multi-step
speed 4 is the high bit.
Multi-step speed terminal 2
Multi-step speed terminal 3
Multi-step speed terminal 4
Shield the multi-step speed selection terminal function
to keep the setting value at the current state.
Select 4 ACC/DEC time by the combination of the 2
terminals.
Restart simple PLC and clear the memory state of
PLC.
Program pause during PLC implement. Run at the
current speed stage. After cancel the function, simple
