Goodrive300 Series VFD Function parameters
56
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P02.17
Number of
poles pairs for
synchronous
motor 1
1–50
Goodrive300 VFDs provide
the parameter autotuning
function. Correct parameter
autotuning depends on the
correct setting of the name
plate parameters of the motor.
To ensure the control
performance, configure the
standard matched motor for
the VFD. If the power of the
motor configured is greatly
different from that of the
standard matched one, the
control performance of the
VFD degrades significantly.
Note: P02.16 to P02.19 may
be initialized by resetting the
rated power of the motor
(P02.15).
2
◎
P02.18
Rated voltage
of
synchronous
motor 1
0–1200V
Depend
on
model
◎
P02.19
Rated current
of
synchronous
motor 1
0.8–6000.0A
Depend
on
model
◎
P02.20
Stator resistor
of
synchronous
motor 1
0.001–65.535Ω
After the motor parameter
autotuning is properly
complete, the values of
P02.20 to P02.22 are updated
automatically. These
parameters are the
benchmark parameters of
high-performance vector
control, directly affecting the
control performance.
When P00.15=1 (rotating
autotuning), the set value of
P02.23 may be automatically
updated by autotuning, In this
case, there is no need to
change the value of P02.23.
When P00.15=2 (static
autotuning), the set value of
P02.23 cannot be updated by
Depend
on
model
○
P02.21
Direct axis
inductance of
synchronous
motor 1
0.01–655.35mH
Depend
on
model
○
P02.22
Quadrature
axis
inductance of
synchronous
motor 1
0.01–655.35mH
Depend
on
model
○
P02.23
Back EMF
constant of
synchronous
motor 1
When P00.15=2,
the set value of
P02.23 cannot
be updated by
autotuning,
please count
300
○
