INVT Goodrive300 Series - Page 60

Goodrive300 Series VFD Function parameters
55
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P02.09
Mutual
inductance of
asynchronous
motor 1
0.1–6553.5 mH
change this group of
parameters at will.
Depend
on
model
○
P02.10
Non-load
current of
asynchronous
motor 1
0.1–6553.5A
Depend
on
model
○
P02.11
Magnetic
saturation
coefficient 1
for the iron
core of AM1
0.0–100.0%
80.0%
◎
P02.12
Magnetic
saturation
coefficient 2
for the iron
core of AM1
0.0–100.0%
68.0%
◎
P02.13
Magnetic
saturation
coefficient 3
for the iron
core of AM1
0.0–100.0%
57.0%
◎
P02.14
Magnetic
saturation
coefficient 4
for the iron
core of AM1
0.0–100.0%
40.0%
◎
P02.15
Rated power
of
synchronous
motor 1
0.1–3000.0kW
Set the parameters of the
controlled synchronous motor
(SM).
To ensure the control
performance, se the values of
P02.15 to P02.19 properly
according to the parameters
on the name plate of the SM.
Depend
on
model
◎
P02.16
Rated
frequency of
synchronous
motor 1
0.01Hz–P00.03
(Max. frequency)
50.00
Hz
◎
