INVT Goodrive300 Series - Page 59

Goodrive300 Series VFD Function parameters
54
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P02.02
Rated
frequency of
asynchronous
motor 1
0.01Hz–P00.03 (Max.
output frequency)
the value of
P02.01–P02.05 based
on the nameplate
parameters.
Goodrive35 series VFD
provides parameter
autotuning function. The
accurate parameter
autotuning requires
proper parameter setup.
In order to ensure
control performance,
configure the motor
based on the motor
which matches with the
VFD. If the gap between
motor power and the
matched motor is too
large, the control
performance of the VFD
will be deteriorated
greatly.
Note: P02.02–P02.10
can be initialized by
resetting rated motor
power P02.01.
50.00
Hz
◎
P02.03
Rated speed
of
asynchronous
motor 1
1–36000rpm
Depend
on
model
◎
P02.04
Rated voltage
of
asynchronous
motor 1
0–1200V
Depend
on
model
◎
P02.05
Rated current
of
asynchronous
motor 1
0.8–6000.0A
Depend
on
model
◎
P02.06
Stator resistor
of
asynchronous
motor 1
0.001–65.535Ω
After motor parameter
autotuning finishes, the
setting value of
P02.06–P02.10 will be
updated automatically.
These parameters are
the basic parameters for
high-performance vector
control, which will impact
the control performance
directly.
Note: Users cannot
Depend
on
model
○
P02.07
Rotor resistor
of
asynchronous
motor 1
0.001–65.535Ω
Depend
on
model
○
P02.08
Leakage
inductance of
asynchronous
motor 1
0.1–6553.5 mH
Depend
on
model
○
