Goodrive300 Series VFD Function parameters
61
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
coefficient of
braking slip
P03.09
Current loop
percentage
coefficient P
Note:
1 These two parameters adjust the PI adjustment
parameter of the current loop which affects the
dynamic response speed and control accuracy
directly. Generally, users do not need to change
the default value.
2 Only apply to the vector control mode without
PG 0 (P00.00=0).
Setting range: 0–65535
1000
○
P03.10
Current loop
integral
coefficient 1
1000
○
P03.11
Torque setting
method
This parameter is used to enable the torque
control mode, and set the torque.
0: Torque control is invalid
1: Keypad setting torque (P03.12)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: Modbus communication setting torque
8: PROFIBUS\CANopen communication setting
torque
9: Ethernet communication setting torque
10: Reserved
Note: For setting modes of 2–10, 100%
corresponds to three times of the rated current of
the motor.
0
○
P03.12
Keypad
setting torque
Setting range: -300.0%–300.0% (rated current of
the motor)
50.0%
○
P03.13
Torque
reference filter
time
0.000–10.000s
0.010s
○
P03.14
Upper
frequency of
forward
rotation in
0: Keypad (P03.16 sets P03.14, P03.17 sets
P03.15)
1: AI1
0
○
