INVT Goodrive300 Series

Goodrive300 Series VFD Function parameters
62
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
vector control
2: AI2
3: AI3
4: Pulse frequency HDI setting upper-limit
frequency
5: Multi-step setting upper-limit frequency
6: Modbus communication setting upper-limit
frequency
7: PROFIBUS\CANopen communication setting
upper-limit frequency
8: Ethernet communication setting upper-limit
frequency
9: Reserved
Note: For setting modes of 1–9, 100%
corresponds to the maximum frequency.
P03.15
Upper
frequency of
reverse
rotation in
vector control
0
○
P03.16
Keypad
setting for
upper
frequency of
forward
rotation
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14;
P03.17 sets the value of P03.15.
Setting range: 0.00 Hz–P00.03 (Max. output
frequency)
50.00
Hz
○
P03.17
Keypad
setting for
upper
frequency of
reverse
rotation
50.00
Hz
○
P03.18
Upper
electromotion
torque
source
This function code is used to select the
electromotion and braking torque upper-limit
setting source selection.
0: Keypad setting upper-limit frequency(P03.20
sets P03.18, P03.21 sets P03.19)
1: AI1
2: AI2
3: AI3
0
○
P03.19
Upper braking
torque
source
0
○
