Goodrive350-19 series VFD Product overview
- 17 -
Note:
 The input current of 1.5–500kW VFD models is measured in cases where the input voltage is
380V without an additional reactor.
 The rated output current is the output current corresponding to 380V output voltage.
 Within the allowable input voltage range, the output current and power cannot exceed the rated
output current and power.
Table 3.4 AC 3PH 520V (-15%) – 690V (+10%)
VFD model
Output power (kW)
Input current (A)
Output current (A)
GD350-19-022G-6
22
35
27
GD350-19-030G-6
30
40
35
GD350-19-037G-6
37
47
45
GD350-19-045G-6
45
52
52
GD350-19-055G-6
55
65
62
GD350-19-075G-6
75
85
86
GD350-19-090G-6
90
95
98
GD350-19-110G-6
110
118
120
GD350-19-132G-6
132
145
150
GD350-19-160G-6
160
165
175
GD350-19-185G-6
185
190
200
GD350-19-200G-6
200
210
220
GD350-19-220G-6
220
230
240
GD350-19-250G-6
250
255
270
GD350-19-280G-6
280
286
300
GD350-19-315G-6
315
334
350
GD350-19-355G-6
355
360
380
GD350-19-400G-6
400
411
430
GD350-19-450G-6
450
445
465
GD350-19-500G-6
500
518
540
GD350-19-560G-6
560
578
600
GD350-19-630G-6
630
655
680
Note:
 The input current of 22–350kW VFD models is measured in cases where the input voltage is
660V without DC reactors or input or output reactors.
 The input current of 400–630kW VFD models is measured in cases where the input voltage is
660V with input reactors.
 The rated output current is the output current corresponding to 660V output voltage.
