INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Dimensional drawings
-491-
Appendix C Dimensional drawings
C.1 What this chapter contains
This chapter describes the dimension drawings of Goodrive350-19 series VFD. The dimension unit
used in the drawings is mm.
C.2 LED keypad
C.2.1 Structural diagram
Keypad
Keypad outline
2-M3x10 Assembly screw
Panel
Opening sizes for installing the keypad without a braket
C.2.2 Keypad installation bracket
Note: You can directly use M3 threaded screws or an installation bracket to externally connect the
keypad to the VFD. The installation bracket is optional for 380V 1.5–30 kW VFD models and 500V
4–18.5 kW VFD models. The installation bracket is a standard part for 380V 37–500 kW VFD models,
500V 22–500 kW VFD models, and all 660V VFD models.
Keypad installation bracket
Installation dimensions
Figure C.1 (Optional) Installation bracket for 380V 1.5–315kW and 660V 22–630kW models
