Goodrive350-19 series VFD Dimensional drawings
-493-
Installation dimensions
Keypad installation bracket
103
98
140
115
4-R12
Figure C.4 (Optional) Installation bracket for 380V 1.5–500kW and 660V 22–630kW models
C.4 VFD structure
Figure C.5 VFD structure
