INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Extension cards
-454-
Extension card installation procedure:
STEP2
STEP3
Re m ov e th e s cr ew s an d t he low er c o ver .
STEP1
STEP4
EC
STEP5
STEP6
Ta k e o ut t he ke yp ad , a nd
rem o v e t he up pe r cove r.
STEP7
Wi re b in din g p os it ion
In stal lati on w iri ng
A fte r th e cu tti ng
Cut o ff the o ut let fram e
co rrespon din g to the E C
po s itio n.
Figure A.3 Extension card installation procedure
A.3 Wiring
1. Ground a shielded cable as follows:
