Goodrive350-19 series VFD Optional peripheral accessories
-519-
INVT provides filters for you to choose.
D.8.1 Filter model description
04
-
CA D E
FLT
L
B
P
045
F
B
-
Field
Description
A
FLT: Name of the VFD filter series
B
Filter type
P: Power input filter
L: Output filter
C
Voltage class
04: AC 3PH 380V (-15%)–440V (+10%)
06: AC 3PH 520V (-15%)–690V (+10%)
D
3-digit code indicating the rated current. For example, 015 indicates
15 A.
E
Filter performance
L: General
H: High-performance
F
Filter application environment
A: Environment Category I, C1 (EN 61800-3:2004)
B: Environment Category I, C2 (EN 61800-3:2004)
C: Environment Category II, C3 (EN 61800-3:2004)
D.8.2 Filter models
Table D.7 AC 3PH 380V(-15%)–440V(+10%)
VFD model
Input filter
Output filter
GD350-19-1R5G-4-B
FLT-P04006L-B
FLT-L04006L-B
GD350-19-2R2G-4-B
GD350-19-004G-4-B
FLT-P04016L-B
FLT-L04016L-B
GD350-19-5R5G-4-B
GD350-19-7R5G-4-B
FLT-P04032L-B
FLT-L04032L-B
