INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 48 -
5.3.3 Macro parameters (P90.00=3)
Function
code
Name
Setting
Remarks
P00.01
Command running channel
1
Terminal
P00.03
Max. output frequency
100.00Hz
P00.04
Upper limit of running
frequency
60.00Hz
P00.06
Setting channel of A
frequency command
6
Multi-step speed running
P00.11
ACC time 1
5.0s
P00.12
DEC time 1
4.0s
P01.01
Starting frequency of direct
start
0.20Hz
P01.15
Stop speed
0.10 Hz
P05.00
HDI input type
0x11
HDIA is digital input
HDIB is digital input
P05.03
Function of S3 terminal
16
Multi-step speed setting terminal 1
P05.04
Function of S4 terminal
17
Multi-step speed setting terminal 2
P05.05
Function of HDIA terminal
7
Fault reset
P05.06
Function of HDIB terminal
6
Coasting to stop
P06.03
RO1 output selection
5
VFD fault
P06.04
RO2 output selection
49
Brake output
P10.02
Multi-step speed 0
10.0%
Corresponding to the max. frequency
P10.04
Multi-step speed 1
30.0%
Corresponding to the max. frequency
P10.06
Multi-step speed 2
60.0%
Corresponding to the max. frequency
P11.05
Current limit selection
0x11
Enable software and hardware
current limit.
P11.26
Enabling special functions
1
P90.04
Enabling brake-oriented logic
1
The brake is controlled by the VFD.
P90.12
Forward brake release
current
50.0%
Corresponding to the motor rated
current
P90.13
Reverse brake release
current
50.0%
Corresponding to the motor rated
current
Note: The macro parameter table does not contain some parameters that are factory default
parameters.
5.3.4 Points for attention
 If you only want to check whether the VFD runs properly, set P90.00=0(Common mode).
