IONPURE IP-VNX-MAX-1 User Manual

APPENDIX A: VNX MODULE SPECIFICATIONS
A.1 VNX Module Dimensions and Weight
Module
Height
inches (cm)
Width
inches (cm)
Length
inches (cm)
Shipping weight
lbs (kg)
Service weight
lbs (kg)
IP-VNX-MINI 20 (50.8) 20 (50.8) 66.14 (168) 620 (281) 835 (379)
IP-VNX-MAX 20 (50.8) 20 (50.8)
84 (213.3) 635 (288)
850 (385)
IP-VNX28EP-2 20 (50.8) 20 (50.8) 44 (111.8)
325 (147) 435 (197)
IP-VNX55EP-2 20 (50.8) 20 (50.8) 84 (213.3) 635 (288) 850 (385)
IP-VNX55E-2 20 (50.8) 20 (50.8) 84 (213.3) 635 (288) 850 (385)
IP-VNX55EX-2 20 (50.8) 20 (50.8) 84 (213.3) 635 (288) 850 (385)
IP-VNX55HH-2 20 (50.8) 20 (50.8) 84 (213.3) 635 (288) 850 (385)
IP-VNX15CDIT-2 20 (50.8) 20 (50.8) 44 (111.8) 325 (147) 435 (197)
IP-VNX30CDIT-2 20 (50.8) 20 (50.8) 84 (213.3) 635 (288) 850 (385)
A.2 VNX Module Inlet & Outlet Connections
Piping Connections Installed PVC Adapters Optional Adapters
Dilute Inlet 1-½ ” female socket, PVC 50 mm butt weld, polypropylene
Product Outlet 1-½ ” female socket, PVC 50 mm butt weld, polypropylene
Concentrate Inlet 1-½ ” female socket, PVC 50 mm butt weld, polypropylene
Reject Outlet 1-½ ” female socket, PVC 50 mm butt weld, polypropylene
See Drawings in Appendix B for location of connections. See Drawings in Appendix C for Connector Drawings.
