106
Step 4: Configure Switch
On the switch, set the port connected to the router as an access port and allow VLAN 100 to pass
through, and set the port connected to the AC as a trunk port and allow VLAN 1,100 to pass through.
The port connected to
VLAN ID
Port Type
PVID
Router1
100
Access
100
AC
1,100
Trunk
1
Verification
After all the configurations are complete, the AC can access the internet and the enterprise network
simultaneously. When the users connect the "VIP" WiFi network, they can access the internet and the
enterprise network simultaneously.
