107
Appendix 1: Final Settings of the AC
After all the configurations are complete, the interface settings and DHCP server settings are shown as
follows.
Interface
Name
Interface
Type
Physical
Port
VLAN
ID
IP Address
DHCP Server
Gateway/Primary DNS
vlan5
VLAN
Interface
eth0
5
192.168.5.1
192.168.5.100-200
192.168.5.1
default
VLAN
Interface
eth0
0
192.168.0.1
Disabled
vlan100
VLAN
Interface
eth0
100
192.168.100.1
192.168.100.150-250
192.168.100.1/202.96.134.1
33
wan0
WAN
Interface
eth3
The IP Routing page is displayed as follows:
Remark
Destination
Network
Subnet Mask
Next Hop
Interface
Status
Default
0.0.0.0
0.0.0.0
172.16.200.1
wan0
Valid
Internal
172.16.100.0
255.255.255.0
192.168.100.100
vlan100
Valid
