indicates that the route is configured incorrectly, if so, verity that the destination network, next hop, and
interface are configured correctly.
Modifying an IP Route
1. Choose Network Setting > IP Routing.
2. Find the route to be modified and click .
3. Configure the parameters in the window.
4. Click Save.
Deleting an IP Route
1. Choose Network Setting > IP Routing.
2. Find the route to be modified and click .
The default route is not allowed to be modified or deleted.
2.3 Example of IP Routing
2.3.1 WAN Interface Is Not Created
Networking Requirement
The AC is connected to two networks: the internet and the enterprise network. All users connected to the
AC need to access the internet and the internal server of the enterprise network simultaneously.
Assumption:
 The network segment of the server: 172.16.100.0/24.
 The LAN IP address of the router connected to the server (Router1): 192.168.100.100.
 The LAN IP address of the router connected to the internet (Router2): 192.168.200.100. This
router is a DNS proxy server.
 The switch and APs are not configured VLAN function. All users do not belong to any VLAN
networks.
 Both the two routers support creating NAT rules.
