19
1.2.3 Example of Interface and DHCP Server
Networking Requirement
The AC has succeeded in managing the APs. The users connected to the APs need to obtain IP
addresses from the AC to access the internet.
Assumption:
Before the configuration, the APs have no management VLAN ID. The SSID policy of the APs
uses the centralized forwarding mode.
The LAN IP address of the router is 192.168.100.50.
The router is a DNS proxy server.
All users belong to VLAN 100.
Network Topology
