Procedure
I. Configure the Switch
In centralized forwarding mode, data of VLAN 100 from the users is encapsulated and invisible to the
switch. So there is no need to set the ports connected to the APs. The VLAN configuration of the other
ports of the switch is shown as follows.
II. Configure the AC to Deliver SSID Policy
Procedure:
Step 1: Create VLAN Interface
1. Log in to the web UI of the AC and go to Network Setting > Network Setting > Interface Settings.
2. Click Add.
3. Configure the parameters in the window.
Interface Type: Select "VLAN Interface".
Physical Port: Select the physical port connected to the switch, which is "eth0".
Interface Name: Set a name for the VLAN interface, such as "vlan100".
VLAN ID: Enter the VLAN ID of the users' VLAN network, which is "100".
4. Click Save.
