2.3.2 WAN Interface Is Created
Networking Requirement
The AC is connected to two networks: the internet and the enterprise network. All users connected to the
AC need to access the internet and the internal server of the enterprise network simultaneously.
Assumption:
The network segment of the server: 172.16.100.0/24.
The LAN IP address of the router connected to the server (Router1): 192.168.100.100.
The switch and APs are not configured VLAN function. All users do not belong to any VLAN
networks.
The applied bandwidth is 50Mbps, and both the PPPoE user name and password are "Nell".
In this example, assume that the DNS address is 202.96.134.133.
Network Topology
