Step 5: Configure Switch
On the switch, set the ports connected to Router1 and Router2 as an access port and allow VLAN 100
and VLAN 200 to pass through respectively. Set the port connected to the AC as a trunk port and allow
VLAN 100,200 to pass through.
The port connected to
VLAN ID
Port Type
PVID
Router1
100
Access
100
Router2
200
Access
200
AC
100,200
Trunk
1
Verification
After all the configurations are complete, the AC can access the internet and the enterprise network
simultaneously. When the users connect the "VIP" WiFi network, they can access the internet and the
enterprise network simultaneously.
