Appendix 1: Final Settings of the AC
After all the configurations are complete, the final settings on the AC are shown as follows.
VLAN ID and IP address settings:
Interface
Name
Interface
Type
Physical
Port
VLAN
ID
IP Address
DHCP Server
Gateway/Primary DNS
vlan5
VLAN
Interface
eth0
5
192.168.5.1
192.168.5.100-200
192.168.5.1
vlan6
VLAN
Interface
eth0
6
192.168.6.1
192.168.6.100-200
192.168.6.1/192.168.200.10
0
default
VLAN
Interface
eth0
0
192.168.0.1
Disabled
vlan100
VLAN
Interface
eth0
100
192.168.100.1
Disabled
vlan200
VLAN
Interface
eth0
200
192.168.200.1
Disabled
The IP Routing page is displayed as follows:
Remark
Destination
Network
Subnet Mask
Next Hop
Interface
Status
Default
0.0.0.0
0.0.0.0
192.168.200.100
vlan200
Valid
Internal
172.16.100.0
255.255.255.0
192.168.100.100
Vlan100
Valid
Appendix 2: Final Settings of the Two Routers
IP Routes:
Configured Router
Destination Network
Next Hop
Interface
Router1
192.168.6.0/24
192.168.100.1
LAN
Router2
192.168.6.0/24
192.168.200.1
LAN
NAT Rule:
Configured Router
IP Address
Subnet Mask
Interface
Router1
192.168.6.0
255.255.255.0
WAN
Router2
192.168.6.0
255.255.255.0
WAN
