98
Step 4: Configure Switch
On the switch, set the ports connected to the APs and the AC as trunk ports, set the PVID of the ports to
1, and allow VLAN 1,5 to pass through the ports. See the following figure.
The port
connected to
VLAN ID
Port Type
PVID
AP, AC
1,5
Trunk
1
End: After the configuration is complete, the AC can manage the APs whose management VLAN ID is 5.
II. Manage User
Log in to the web UI of the AC and follow the steps.
