iPECS eMG80
System DECT Installation Guide Issue 1.3
3
2.1 General Specifications
Table 2.1-1 Environmental Specifications
ITEM DEGREES (
℃
) DEGREES (
℉
)
Operation Temperature
0~40
32~104
Optimum Operation Temperature
20~26
68~78
Storage Temperature
10~70
32~158
Relative Humidity
0~80% non-condensing
2.2 WTIB4 Specifications
ITEM SPECIFICATION
WTIB4
Power Consumption
3.3W (= 660mA @ +5V)
DECT base station connection port
4
DECT base station interface
E1(line coding : HDB3)
DECT base station feeding voltage
+30V (±2.5%)
Serial Port for GDK-TRC1
1 (115,200bps); ELG proprietary 4-pin serial interface
2.3 GDC-600BE Specifications
Table 2.3-1 Base Station Specifications
ITEM SPECIFICATION
Power feeding +30VDC
Transmission Max Power 250mW
100mW(USA)
Access Method/Duplex TDMA/TDD
Frequency Band 1,880~1,900MHz
1920~1930MHz (USA)
Channel Spacing 1.728MHz
Modulation GFSK
Data rate 1.152Mbps
Max. Base Station distance from the WTIB4 600m (twisted 2-pair cable)
