C
HAPTER
8
| Spanning Tree Algorithm
Configuring Multiple Spanning Trees
– 223 –
To use multiple spanning trees:
1. Set the spanning tree type to MSTP (page 209).
2. Enter the spanning tree priority for the selected MST instance on the
Spanning Tree > MSTP (Configure Global - Add) page.
3. Add the VLANs that will share this MSTI on the Spanning Tree > MSTP
(Configure Global - Add Member) page.
N
OTE
:
All VLANs are automatically added to the IST (Instance 0).
To ensure that the MSTI maintains connectivity across the network, you
must configure a related set of bridges with the same MSTI settings.
PARAMETERS
These parameters are displayed in the web interface:
◆ MST ID – Instance identifier to configure. (Range: 0-4094)
◆ VLAN ID – VLAN to assign to this MST instance. (Range: 1-4093)
◆ Priority – The priority of a spanning tree instance. (Range: 0-61440 in
steps of 4096; Options: 0, 4096, 8192, 12288, 16384, 20480, 24576,
28672, 32768, 36864, 40960, 45056, 49152, 53248, 57344, 61440;
Default: 32768)
