Better Packages Section 1
Unpacking and Setup
11
There are two other components on the electrical panel:
• The 9-Pin female connector that can be used:
On Standard and Automatic models to attach a pedal switch. On Automatic models (only) to access an
RS-232 serial data port. Using this data port, the Better Packages Automatic Measuring Device (AMD-1)
(purchased separately) can be utilized to instantly measure & dispense the exact length as tape needed.
• A user-replaceable fuse.
See the Maintenance Section
3. Plug the male end of the power cord into a 110/120v 60hz receptacle.
If you are not sure if the electrical system in your building is properly grounded, contact a licensed
electrician.
port for
optional
pedal
control
or AMD-1
Holder
the A/C
Power
Cord
here
WARNING: FOR YOUR SAFETY
All metal parts of this machine are
electrically grounded through a
3-wire power supply. You must plug
this cord into a 3-
receptacle.
