IPSO DR30SLG - Page 52

Page 52
Parts—30 lb. Dryer (Rear of Dryer)
37 TU5439 5/16"-18 x 3/4" Hex Head Screw
38- - Motor (Specify Motor No.,
Voltage, Cycle and Horsepower)
39 TU4684 Key
41 TU6559 Motor Sheave—60 Hz.
TU7603 Motor Sheave—50 Hz.
42 VSB134 3/8" Lockwasher
43 CFB3000 Cable—1/2" x 30" Lg.
44 PT196 Cable Strap
45 TU5850 Motor Mount—50/60 Hz.
46 TU4790 Straight Connector (2 Req’d)
47 TU2474 Gasket (2 Required)
48 TU4684 Key
49 TU13408 5/16"-18 x 1/2" Set Screw Nylok
50 TU11708 Rear Guard—“UR” Models
TU10134 Rear Guard—“US” Models
TU10131 Right Rear Cover—”US” Models
51 TU10433 Locking Collar Label
52 TU10418 Lubrication Label
53 TU10010 Jacket Welded Assembly
54 OP251 1/2" Int. Tooth Lockwasher
55 OP233 1/2" Hex Nut
56 TU2195 1/2"-13 x 1-3/4" Cap Screw
57 TU2883 1/2" Flat Washer
62 TU10651 Mechanism Box Cover
(Steam Dryer Only)
63 TU10177 Spacer (Mounted Inside Jacket)
64 SB170 Junction Box Cover
65 TU2372 Snap Bushing
67 TU10359 Motor Adapter—3 Ph. Only
68 TU13044 Motor Adapter—1 Ph. Only
* See separate page for exploded view.
** Eccentric Locking Collar W/Set Screws
Included
1 TU7733 #8 x 1/2" Self Drill Screw
2 TU3211 3/8-16 x 2-1/2" Leveling Bolts
3 TU4937 3/8-16 Jam Nut
5 TU4787 3/8-16 Hex Nut
6 VSB134 3/8" Split Lockwasher
7 TU12803 Idler Bracket
8 TU12576 3/8-16 x 1" Carriage Bolt
9 TU3247 Retaining Ring
10 TU7184 Sleeve Bearings (2 required)
11 TU5217 14" Idler Sheave (50/60 Cy.)
12 TU3395 V-Belt (4L580) 50 Hz.
TU7021 V-Belt (4L570) 60 Hz.
13 TU3395 V-Belt (4L580) 50/60 Hz.
14 TU5887 Key
15 TU7016 15" Basket Sheave (50/60 Cy.)
16 TU10676 Pillow Block Bearing**
17 TU13147 Bearing Support Bracket
18 TU2831 1/2" Split Lockwasher
19 RC347 1/2"-13 x 1-1/2" Cap Screw
20 TU13372 3/8"-16 Jam Nut w/Nylon Insert
21 TU10002 Flange Basket Bearing**
22 TU13480 Transformer - 240V/24V
TU13515 Transformer - 120V/24V
TU13514 Transformer - 460V/24V
TU13642 Transformer - 575V/24V
TU13643 Transformer - 380-415V/24V
23 TU8206* Air Switch Assembly
25 TU6263 Hex Hd. Screw
26 IB140 3/8" Washer
27 TU5890 Control Box Cover
28 TU13463 Relay - 9A, 3 Pole w/Aux.
TU13516 Relay - 12A, 3 Pole w/Aux.
29 TU8746 Fan, 60 Hz. W/Set Screws
TU5874 Fan, 50 Hz. W/Set Screws
30 TU9272 5/16" Nylon Patch Set Screw
31 TU2476 Felt Seal
32 TU2473 Side Gasket (2 Required)
33 C249 5/16"-18 Hex Nut
34 TU2814 5/16" Split Lockwasher
35 TU4787 3/8"-16 Hex Nut
36 VSB130 5/16" Cut Washer
