21
Programming mode 4
A XX = Action Time (Cycle Time)
Put in the action time (0 to 60 seconds) with " X,X ".
If the motor is frequency controlled, one decimal digit will appear which enables you to set the time accurately
to 0.1 seconds.
When " 0 " is put in (cycle without cylinder rotation), the next step (" S XX ") will be skipped.
Press " E ".
S XX = Stop time (Pause time)
Put in the pause time (1 to 60 seconds) with " X,X ".
If the motor is frequency controlled, one decimal digit will appear which enables you to set the time accurately
to 0.1 seconds. (Minimum 0.5 seconds)
Press " E ".
The next step depends on the selection during the "preprogram".
- With " no FC " (no frequency controlled motor): transition to " XX. tEMP ".
- With " FC " (frequency controlled motor): transition to " SP XX ".
SP XX = Speed
Put in the rpm speed of the wash cycle (10 to 50 rpm) with " X,X ".
Press " E ".
XX. tEMP = Temperature (temperature of the bath)
Press " E ".
°C XX = Temperature (Or °F XX °C or °F according to the setting in the Preprogramming).
Indicate the temperature (maximum 95°C) with X,X and press E .
If a cold wash bath is desired, select 0 . Now, the display will immediately show XX. SE-i .
The next step will depend on the setting selected during the preprogramming at HEAt-SYS .
å
If HEAt-Mod was selected, then NO will allow to choose between:
HEAt (heating without modulation) with transfer to HECo or XX. SE-i .
HEAt-Mod (modulation with additional heating) with transfer to HECo or XX. SE-i .
Mod (modulation without additional heating) with transfer to HECo or XX. SE-i .
Now press E .
If HEAt was selected, the display will immediately go to HECo or XX. SE-i .
If Mod was selected, the display will immediately go to XX. SE-i .
å
å
