Introduction 1
Microprocessor PC30
Machines equipped with the electronic freely programmable microprocessor PC30 allow you to program 30
programs ( 0 to 29) of your own choice. There are also 10 standard programs ( 30 to 39) available. The operation
of the machine, as well as the input of data necessary to obtain a wash program occur via the keyboard in the fascia
panel.
Flow charts
In this manual flow charts are frequently used. Below you can find an explication of the applied symbols.
This gives a presentation of a text that appears on the display.
These symbols with rounded off corners stand for pressing the appropriate keys
on the keyboard.
e.g. numbers, start, stop, etc. (X stands for a number of your choice).
The symbols in rectangulars stand for mechanical interventions that need to be
executed.
e.g. turning the key switch in the front.
The representation of a rhomb refers to a software requirement.
e.g. has a frequency controlled motor been selected in the preprogram or not, has
a coin-op machine been selected or not, etc.
